Nvidia BlueField BF1600 User Manual

32
SPI Flash Memory
The SPI Flash memory is used for storing the NIC firmware as of the ConnectX-5 Flash memory. The SPI Flash memory size is 128Mb.
Networking LED Interfaces
There is a one bi-color I/O LED per port to indicate link status. See t
he below figure for the networking LEDs locations on the BF1600 Controller Card
bracket. For LED specifications, please refer toNetworking LED Interfaces.
CPLD Revision LEDs Interface
There are four green I/O LEDs to indicate CPLD revision located on the BlueField BF1600 Controller Card. See the below figurefor the CPLD LEDs location
on the card. For LEDs specifications, please refer toCPLD Revision LEDs Interface
.

Nvidia BlueField BF1600 Specifications

General

Brand	Nvidia
Model	BlueField BF1600
Category	PCI Card
Language	English
