72 GND Ground
73 GND Ground
74 HSOp(14)
Input
BlueField Card PCIE RX to Carrier Board PCIE TX
75 HSOn(14)
76 GND Ground
77 GND Ground
78 HSOp(15)
Input
BlueField Card PCIe RX to Carrier Board PCIe TX
79 HSOn(15)
80 GND Ground
81 PRSNT#2 Output PRSNT#2 - Hot plug present detect
82 RSVD NA For testing purposes only. Keep it floating.
PCIe Gen 3.0 through Two CABLINE-CA II PLUS Connectors
The BlueField BF1600 Controller Card uses two x8 CABLINE-CA II PLUS connectors (Component Side and Print Side Connectors) according to the PCI Express
3.0 specifications. The below two tables provide the component side pins description and the print side pins description. For further details, please refer
toPCIe Gen 3.0 through Two CABLINE-CA II PLUS Interfaces
.
