46
58 HSOp(10) 
Input

BlueField Card PCIE RX to Carrier Board PCIE TX
59 HSOn(10)
60 GND Ground
61 GND Ground
62 HSOp(11) 
Input

BlueField Card PCIe RX to Carrier Board PCIe TX
63 HSOn(11)
64 GND Ground
65 GND Ground
66 HSOp(12) 
Input

BlueField Card PCIe RX to Carrier Board PCIe TX
67 HSOn(12)
68 GND Ground
69 GND Ground
70 HSOp(13) 
Input

BlueField Card PCIe RX to Carrier Board PCIe TX
71 HSOn(13)
