45
45 HSOp(7) 
Input

BlueField Card PCIe RX to Carrier Board PCIe TX
46 HSOn(7)
47 GND Ground
48 PRSNT#2 NA Not Connected.
Assembly option for on-board CPLD connectivity
49 GND Ground
50 HSOp(8) 
Input
BlueField Card PCIe RX to Carrier Board PCIe TX
51 HSOn(8)
52 GND Ground
53 GND Ground
54 HSOp(9) 
Input

BlueField Card PCIe RX to Carrier Board PCIe TX
55 HSOn(9)
56 GND Ground
57 GND Ground
