Secure the BF1600 Controller Card to the JBOF system.
Step 1. Secure the bracket to the JBOF system with the bracket screw.
BF1600 Controller and Auxiliary Connection Cards Installation Instructions - PCIe x32
Do not use excessive force when seating the card, as this may damage the system or the auxiliary PCIe connection card.
Applies to MBF1M626A-CSNAT, MBF1M636A-CSNAT and MBF1M656A-CSNAT.
