Pin Description
PCI Express Interface
PCIe x16 Gen 3.0/4.0 Edge Connector
The BF1600 Controller Card uses a PCI Express x16 connector (component and print sides) according to the PCI Express 3.0/4.0 specifications. The
following two tablesprovide component side pins description and print side pins description. For further details, please refer toPCIe x16 Gen 3.0/4.0 Edge
Interface.
PCIe x16 Edge Connector Pins Description - Print Side
Pin# Pin Name
Pin Direction
a
Description
1 PRSNT#1 Input The presence detects indication. Should be grounded on the carrier board.
2 +12v Input Power
3 +12v Input Power
4 GND Ground
5 JTAG_HOST_TCK Input No connected
6 JTAG_HOST_TDI Input No connected
HSOp(x) and HSOn(x) stand for High Speed Output and HSIp(x) and HSIn(x) stand for High Speed Input. The direction is relative to the motherboard
or system board.

