PCIe Auxiliary Connection Card
The PCIe Auxiliary Card is a 5.09in. x 2.32in. (129.30mm x 59.00mm) card. The below figuresprovide the connector designations.
PCIe Auxiliary Connection Card - Component Side
The PCIe Auxiliary Connection card is supplied with the following OPNs: MBF1M626A-CSNAT, MBF1M656A-CSNAT and MBF1M636A-CSNAT.
The below figures are for illustration purposes only and might not reflect the current revision of the BF1600 card.
