Color Signal Description
Orange TXD Transmit Asynchronous Data output. Connects to RXD input on Controller Card
UART Cable Connected to BF1600 Card
USB Interface Cabling
Debugging and loading new versions of the operating systems and firmware requires the use of Type A to Type B USB 2.0 Cable. The following figure shows
an example of Type A to Type V USB Cable.
