Nvidia BlueField BF1600 - Page 44

44
30 RSVD NA For testing purposes only. Keep it floating.
31 PRSNT#2 NA For testing purposes only. Keep it floating.
32 GND Ground
33 HSOp(4) 
Input

BlueField Card PCIe RX to Carrier Board PCIe TX
34 HSOn(4)
35 GND Ground
36 GND Ground
37 HSOp(5) 
Input

BlueField Card PCIe RX to Carrier Board PCIe TX
38 HSOn(5)
39 GND Ground
40 GND Ground
41 HSOp(6) 
Input

BlueField Card PCIe RX to Carrier Board PCIe TX
42 HSOn(6)
43 GND Ground
44 GND Ground
