14 HSOp(0)
Input
BlueField Card PCIe RX to Carrier Board PCIe TX
15 HSOn(0)
16 GND Ground
17 PRSNT#2 NA Not Connected.
Assembly option for on-board CPLD connectivity
18 GND Ground
19 HSOp(1)
Input
BlueField Card PCIe RX to Carrier Board PCIe TX
20 HSOn(1)
21 GND Ground
22 GND Ground
23 HSOp(2)
Input
BlueField Card PCIe RX to Carrier Board PCIe TX
24 HSOn(2)
25 GND Ground
26 GND Ground
27 HSOp(3)
Input
BlueField Card PCIe RX to Carrier Board PCIe TX
28 HSOn(3)
29 GND Ground
