Pin# Name PCIe Description Description
1 +12v Input Power
2 +12v Input Power
3 +12v Input Power
4 GND Ground
5 SMCLK Input SMBUS_SCL - connected to BlueField SoC SMB2 Inter- face SCL
6 SMDAT bidirectional SMBUS_SDA - connected to BlueField SoC SMB2 Inter- face SDA
7 GND Ground
8 +3.3v Input Power
9 JTAG_TRS T# Input For testing purposes only. Keep it floating.
10 3.3Vaux Input 3.3V_AUX
11 WAKE# NA Not Connected.
Assembly option for on-board CPLD connectivity
Mechanical Key
12 RSVD NA For testing purposes only. Keep it floating.
13 GND Ground
