20 GND Ground

21 HSIp(1) 

Output



BlueField Card PCIe TX to Carrier Board PCIe RX

22 HSIn(1)

23 GND Ground

24 GND Ground

25 HSIp(2) 

Output



BlueField Card PCIe TX to Carrier Board PCIe RX

26 HSIn(2)

27 GND Ground

28 GND Ground

29 HSIp(3) 

Output



BlueField Card PCIE TX to Carrier Board PCIe RX

30 HSIn(3)

31 GND Ground

32 RSVD Input UART0_RXD - Connected to BlueField SoC UART0 RX

33 RSVD Output UART0_TXD - Connected to BlueField SoC UART0 TX

34 GND Ground
