Nvidia BlueField BF1600 - Page 40

40
69 HSIn(12)
70 GND Ground
71 GND Ground
72 HSIp(13) Output BlueField Card PCIe TX to Carrier Board PCIe RX
73 HSIn(13)
74 GND Ground
75 GND Ground
76 HSIp(14) Output BlueField Card PCIe TX to Carrier Board PCIe RX
77 HSIn(14)
78 GND Ground
79 GND Ground
80 HSIp(15) Output BlueField Card PCIe TX to Carrier Board PCIe RX
81 HSIn(15)
82 GND Ground
a. From BlueField BF1600 Controller Card Perspective.
