29 HSO_7N Input BlueField Card PCIe RX to Carrier Board PCIe TX
30 HSO_7P
31 GND Ground
32 HSO_6N Input BlueField Card PCIe RX to Carrier Board PCIe TX
33 HSO_6P
34 GND Ground
35 HSO_5N Input BlueField Card PCIe RX to Carrier Board PCIe TX
36 HSO_5P
37 GND Ground
38 HSO_4N Input BlueField Card PCIe RX to Carrier Board PCIe TX
39 HSO_4P
40 GND Ground
41 HSO_3N Input BlueField Card PCIe RX to Carrier Board PCIe TX
42 HSO_3P
43 GND Ground
44 HSO_2N Input BlueField Card PCIe RX to Carrier Board PCIe TX
45 HSO_2P
