7 RSVD NA Not Connected.

Assembly option for on-board CPLD connectivity

8 RSVD NA Not Connected.

Assembly option for on-board CPLD connectivity

9 GND Ground

10 HSI_0P

Output BlueField Card PCIE TX to Carrier Board PCIE RX

11 HSI_0N

12 GND Ground

13 HSI_1P

Output BlueField Card PCIE TX to Carrier Board PCIE RX

14 HSI_1N

15 GND Ground

16 HSI_2P

Output BlueField Card PCIE TX to Carrier Board PCIE RX

17 HSI_2N

18 GND Ground

19 HSI_3P

Output

BlueField Card PCIE TX to Carrier Board PCIE RX
