Chapter 4. Motherboard Tray -
Accessing in Place
You will need to access the motherboard tray in order to service the following components. This pro-
cess provides access to the motherboard components while the motherboard remains attached to
the server.
▶ M.2 NVMe drives
▶ M.2 module riser card
▶ Motherboard tray battery
▶ Single-port or dual port CX-6 PCI network adapter card
4.1. Accessing the Motherboard Tray
1. Loosen the two motherboard thumbscrews and then pull the handles out to eject the mother-
