Nvidia DGX A100 Service Manual

Chapter 10. M.2 NVMe Boot Drive
Replacement
10.1. M.2 NVMe Boot Drive Replacement
Overview
This is a high-level overview of the procedure to replace a boot drive.
1. With the help of NVIDIA Enterprise Support, determine which M.2 drive needs to be replaced.
2. Get replacement from NVIDIA Enterprise Support.
3. Power down the system.
4. Label all cables and unplug them from the motherboard tray.
5. Slide motherboard out until it locks in place.
6. Open rear compartment and pull out the M.2 riser card with both M.2 disks attached.
7. Replace the failed M.2 device on the riser card.
8. Install the M.2 riser card with both M.2 disks.
9. Close the rear motherboard compartment and then slide the motherboard back into the system.
10. Plug in all cables using the labels as a reference.
11. Power on the system.
12. Conrm the M.2 RAID 1 mirror is synchronizing.
13. Ship back the failed unit to NVIDIA Enterprise Support using the packaging provided.
10.2. Identifying the Failed M.2 NVMe
The DGX A100 system automatically sets the failed M.2 drive oine when it detects the failure.
1. Identify which of the M.2 drives has failed (nvme0n1 or nvme1n1).
$ sudo nvsm show health
2. You can conrm this by issuing the following.
39

Nvidia DGX A100 Specifications

General

GPU	8 x NVIDIA A100 Tensor Core GPUs
System Memory	1 TB DDR4
Storage	15 TB NVMe SSD
GPU Memory	320 GB total (40 GB per GPU)
CPU	2 x 64-Core AMD EPYC 7742
Networking	8 x 200 Gb/s InfiniBand or Ethernet
Interconnect	NVIDIA NVLink
