CASE FRONT AND REAR DIMENSIONAL FEATURES
10
--- Case Front ---
* Note: A 6-foot power cord is supplied and exits the display through the lower rear panel (as shown immediately above).
Refer to your particular model’s specification sheet for electrical requirements and plug configuration.
--- Case Rear ---
4.09*
.75*
NOTE: THE FOLLOWING COUNTER INSTALLATION INFORMATION PERTAINS ONLY
TO MODELS CO33R, CO43R, CO53R and CO63R “UNDER-COUNTER” UNITS
CASE
MINIMUM “X”
DIMENSION
CO33R 34”
CO43R 45”
CO53R 57”
CO63R 69”
CASE “X” DIMENSION
CO33R 36.25”
CO43R 47.25”
CO53R 59.25”
CO63R 71.25”
