MAINTENANCE - MODEL CO4836R.5716 & CO4836RG.5716 WITH REMOVABLE BREAD DISPLAY
1. Merchandiser Overview
• Model CO4836R.5716 and CO4836RG.5716
also have s a bread display unit that sits atop
counter and is protected by a glass sneeze
guard. This bread display unit is also separately
manufactured by SCC as Model BDXXXX.
• Stainless steel posts hold sneeze guards in
position.
• Sneeze guards are glass (sides and top).
• Acrylic bread bins and bread display supports
are removable.
• Stainless steel brackets suspend bread display.
• Stainless steel removable wrap cubbies are
accessible at case rear.
• See illustration below.
2. Rear Panel Removal (For Cleaning Purposes)
• See MAINTENANCE - REAR COMPONENT
LAYOUT (MODEL CO3436RG.5716 ONLY)
section in this manual for location of the six (6)
rear panel attachment points.
• Removing screws at these attachment points will
allow entire rear panel to be removed from case.
Acrylic Bread
Bins
Removable Wrap
Cubbies
Glass Sneeze Guard
(Front, Sides & Top)
Suspended Bread
Display Bracket
(One at Each Side)
Acrylic Bread
Display Supports
(Typical)
Frame Support
Rail (Typical)
Rear Splash
Guard
Removable
Writing
Instrument (Pens
& Markers) Cup
Salad Tissue
Box Holder
Removable Sanitary
Wipe Bucket (Holes Are
SCC-Provided / Bucket
and Hardware Are
Customer- Provided)
Removable
Sanalite Cutting
Board
Removable Bread Display (Also Separately
Manufactured As SCC Model BDXXXX)
Rear Panel (Shown
Transparent For
Illustrative Purposes Only)
