CASE FRONT AND REAR DIMENSIONAL FEATURES
14
--- Case Front ---
* Note: A 6-foot power cord is supplied and exits the display through the lower rear panel (as shown immediately above).
Refer to your particular model’s specification sheet for electrical requirements and plug configuration.
--- Case Rear ---
4.09*
.75*
NOTE: THE FOLLOWING COUNTER INSTALLATION INFORMATION
PERTAINS ONLY TO MODELS CO3324R, CO4324R, CO5324R and CO6324R
CASE
MINIMUM “X”
DIMENSION
CO3324R 34”
CO4324R 45”
CO5324R 57”
CO6324R 69”
CASE “X” DIMENSION
CO3324R 36.25”
CO4324R 47.25”
CO5324R 59.25”
CO6324R 71.25”
