Oasis CO33R - Maintenance - Removable Front Panels (Non-Magnetic)

20
MAINTENANCE - REMOVABLE TOE-KICKS (NON-MAGNETIC) / REMOVABLE RISERS (STEPS)
1. Removable Toe-Kicks
• Front toe-kick is removable.
• Simply lift up and off.
• After case is in desired position, use silicone
sealant to seal toe-kick to floor.
• See previous page for adjustable front toe-kicks
(with screws) on models CO33R, CO43R,
CO53R, CO63R, etc.
• See next page for magnetic removable front
panels.
2. Product Risers (aka “Steps”)
• Risers (“steps”) allow product to be more
prominently displayed.
• Risers are to rest on decks and be placed as far
back as possible (up against rear plenum) as
shown in illustration below.
• See GENERAL CLEANING (TO BE
PERFORMED BY STORE PERSONNEL) -
INTERIOR in manual for instructions on cleaning
risers/steps.
Hooks (Typical)
Front Panel
(With Slots For Hooks)
Product Risers
(aka “Steps”)
Rear Plenum
