CASE TOP AND UNDERSIDE DIMENSIONAL AND LAYOUT FEATURES
12
--- Case Top ---
TO FRONT OF DISPLAY;
NOT INCLUDING THE
WALL & WITH COUNTER
EXTENDED IN FRONT
OF TOP BOARD 1/16”
--- Case Underside ---
3.00 MINIMUM
OPENING ABOVE
TOE-KICK
NOTE: THE FOLLOWING COUNTER INSTALLATION INFORMATION PERTAINS ONLY
TO MODELS CO33R, CO43R, CO53R and CO63R “UNDER-COUNTER” UNITS
CASE
MINIMUM “X”
DIMENSION
CO33R 34”
CO43R 45”
CO53R 57”
CO63R 69”
CASE “X” DIMENSION
CO33R 36.25”
CO43R 47.25”
CO53R 59.25”
CO63R 71.25”
