Oasis CO33R - Maintenance - Optional Security Cover; Optional Flip-Down Door

26
MAINTENANCE - OPTIONAL SECURITY COVER / OPTIONAL REAR FLIP-DOWN HINGED DOOR
1. Security Covers (Optional) - Models COXXRM
• Security covers are designed to prevent
access to merchandiser.
• Security cover is to be placed OVER upper latch
retaining clip and UNDER lower latch
retaining clip.
• Lift security cover up and off with handles.
2. Locking Mechanism
• Locking mechanism key allows plate cam lock to
be rotated under upper retaining clip.
• Proper rotation of plate cam lock prevents cover
from being removed.
3. Key Storage / Cover Storage
• When security cover is attached to case,
remove keys and store in easy-to-remember, yet
secure location.
• When security cover is removed from case, store
in safe, secure location away from foot traffic.
4. Rear Flip-Down Hinged Door (Optional)
• Certain models have a rear, flip-down hinged
door with perforated panel (to maintain proper
airflow).
• Handle is to be pulled outward to open door.
• Caution! Hold door securely while lowering
it against hinges.
• If door is allowed to fall downward onto it
own weight, it can damage hinges.
• Models include CO43R-FS as well as others.
• See illustration below.
Model CO43RM Under Counter Unit With
Optional Locking Security Cover Intact
Lower Retaining Clip
End
Panel
End
Panel
Upper
Retaining
Clip
Plate Cam
Lock
Key/Locking
Mechanism
Cover
Handle
Flip-Down
Door
Hinges (Typ.)
Model CO43R-FS
Shown Below
Handle (Typ.)
Model CO43RM Under Counter Unit
With Optional Locking Security Cover Removed
