Oasis CO33R - Side Section Dimensional and Layout Features

SIDE SECTION DIMENSIONAL AND LAYOUT FEATURES
11
--- Side Section Without O.E.M. Toe-Kick ---
--- Side Section With Full Dimensions --- --- Side Section ---
--- Side Section With O.E.M. Toe-Kick ---
COUNTER
3.00
NOTE: THE FOLLOWING COUNTER INSTALLATION INFORMATION PERTAINS ONLY
TO MODELS CO33R, CO43R, CO53R and CO63R “UNDER-COUNTER” UNITS
DISCHARGE THROUGH
CUSTOMER SUPPLIED
COUNTER TOE-KICK
