Oasis CO33R - Maintenance - Optional Night Air Curtain Operating Instructions

MAINTENANCE - OPTIONAL NIGHT AIR CURTAIN OPERATING INSTRUCTIONS
23
NOTE: THE
BELOW
ILLUSTRATION
MAY NOT
EXACTLY
REFLECT
EVERY
PARTICULAR
CASE’S
FEATURES OR
OPTIONS.
Night Air Curtain Installation & Operating Instructions
1. Use caution when handling night air curtain.
2. Display case may come with night curtain already attached. If not, a retrofit kit will
be provided. If using SCC-supplied retrofit kit, attach to display case by centering
night curtain along top-front of case as shown in illustration below. Attachment
magnets will hold night air curtain firmly in place.
3. Grasp the handle and pull downward to desired location in front of case (as shown
in illustration below).
4. To return night air curtain to its retracted position, grasp handle, lift up and away
from its magnetic attachment and carefully wind night air curtain back into roll.
5. Caution! Do not allow spring-loaded night air curtain to freely snap back into roll.
Doing so can eventually destroy night air curtain’s tension and retractability.
6. To entirely detach night air curtain from case, simply pull it downward and away
from case. Caution! Do NOT drag night air curtain along top (underside) of case
or magnets may scratch or mar surface. Simply lift night air curtain downward and
away from case. Store in safe place away from foot-traffic.
7. Store in a safe and secure space until needed again.
Night Air Curtain Retraction Magnets
Attachment Points
View of Night Air Curtain
(Underside / Detached /
and Rotated) For Illustration
Purposes Only
Acrylic
Sneeze
Guard)
Night Air Curtain
Retraction Magnet
Night Air Curtain
Attachment Magnet
Night Air Curtain
Retraction Magnet
Night Air Curtain
Attachment Magnet
View of Night Air
Curtain (Attached)
Optional Product Step
(Not on All Cases)
Shown For Illustrative
Purposes Only
