Options
99
Installing extra memory B
a Turn off the machine’s power switch.
Unplug the telephone line cord.
b Disconnect the interface cable from the
machine, and then unplug the power
cord from the AC power outlet.
Note
Be sure to turn off the machine’s power
switch before you install or remove the
DIMM.
c Remove the DIMM cover and interface
access cover.
d Unpack the DIMM and hold it by its
edges.
CAUTION
To prevent damage to the machine from
static electricity, DO NOT touch the
memory chips or the board surface.
e Hold the DIMM by the edges and align
the notches in the DIMM with the
protrusions in the slot.
Insert the DIMM diagonally (1), then tilt it
toward the interface board until it clicks
into place (2).
f Put the interface access cover and the
DIMM cover back on.
g Plug the machine’s power cord back into
the AC power outlet first, and then
connect the interface cable.
h Plug in the telephone line cord.
Turn on the machine’s power switch.
