OEM PF/500 - Identification of the Components; Identification of the Machine

PIZZAFORM
Transport and unpacking
GB - 9
FIG. 4
kW
Volt
HzA
Type
Nr
Ali SpA
Viale Lombardia, 33
BOZZOLO (MN)
8
1
2
3
4
5
9
6
7
8
9
2.5 - IDENTIFICATION OF THE COMPONENTS
(Fig. 4)
1. Upper dish
2. Lower dish
3. Safety top and machine function enabling
4. Control element board
5. Supporting feet
6. Lifting eyebolt
7. Electric power supply cable
8. Data plate
9. Trailer-mounted support (Optional)
2.6 - IDENTIFICATION OF THE MACHINE
(Fig. 4)
The serial number and identification data of the machine
are punched on a plate (8) fastened to the machine base.
IMPORTANT
The mac hine serial n umber should be al ways
mentioned in your request of tec hnical assistance
or in your spare part orders.
