OEM PF/500 - 6.1.c.c Dish Resistance Replacement

PIZZAFORM
Maintenance
GB - 23
FIG. 4
1
2
3
4
5
6
7
8
6.1.c.c - Dish resistance replacement (Fig 4)
• Unscrew the screws (1) and remove the cover (2).
• Remove the insulating disk (3).
• Remove the iron plate (4).
• Unscrew the scre ws (5) with the rele vant washers
(6) and (7).
• Remove the resistance (8) and replace it.
• Reassemble everything by proceeding in the reverse
order.
