OEM TL 45 - Applied Safety Pictograms

EC-compliant use and warning instructions
Page 26
CHAPTER 3 – SAFETIES
3.7. Applied safety pictograms
On the machine are applied stickers and safety tags, as shown in the following table. For positioning, refer to the image.
POS.
PICTOGRAM
DESCRIPTION
1
Electrical danger!
2
high temperatures danger!
3
It indicates the terminals that, when connected together, bring the various parts of an
equipment or system to the same potential, not necessarily the ground potential
(ground) (IEC 60417-5021).
1
2
2
3
