EC-compliant use and warning instructions
CHAPTER 5 – TRANSPORT AND INSTALLATION
5.3.1. Group and Weight Division Table
Follow the table below to see which and how many separate parts the oven will be transported to.
L = 1650 mm
P = 1160 mm
H = 550 mm
5.3.2. Transport operations
ATTENTION!
OEM ALI GROUP S.R.L A SOCIO UNICO takes no responsibility for any damage to the machine
resulting from non-compliance with the instructions provided.
IMPORTANT!
Lifting personnel must be authorised and trained in the use of lifting equipment and must comply with
the requirements for individual protection.
Conductor of lifting means
ATTENZION!
Use only suitable and approved lifting means, compatible for the size and weight of the machine.
ATTENTION!
Make sure no one is under and within the range of the lifting mean.
To successfully transport by forklift, follow these steps:
Place the fork of the forklift under the worktop of the machine.
Ensure that the fork comes out from the back of the load (at least 5 cm), for a sufficient length to
eliminate any risk of overturning the transported part.
Lift the forks until the contact with the load
Note: If necessary, attach the load to the fork with clamps or similar devices.
Slowly lift the load by a few tens of centimeters and check its stability by making sure that the load
center of gravity is positioned in the center of the lift fork.
