OHAUS FC5706 - Submenu Motor Start; Submenu Duty Cycle

CHAPTER 2 SEVICE MENU
Ohaus Corporation www.ohaus.com 2-2 FC5706 Centrifuge Service Manual
2.1.2 Submenu Motor Starts
Here you can read off the number of motor starts.
 Activate the operation menu as described in chapter 2.1.1.
 Turn the potentiometer (8) until the special digit “service A “appears in the display
„acc/dec” (A-2), see figure 9
Figure 2
In the display “rpm/rcf“ (A-1) the number of motor starts is indicated now.
2.1.3 Submenu Duty Cycle
Here you can read off the duty cycle of the unit.
 Activate the operation menu as described in chapter 2.1.1.
 Turn the potentiometer (8) until the special digit “service H“ appears in the display
“acc/dec” (A-2).
Figure 3
Inside the display “rpm/rcf“ (A-1) now the duty cycle is indicated.
