SERVICE INSTRUCTIONS
Ohaus Corporation www.ohaus.com 3-11 FC5706 Service Manual
3.3.10 Replacing the power board / control board
 Remove the housing as described in chapter 3.3.5.
 Remove all cable connections to the control board.
 Remove the four fixings screws and take the control board out.
Figure 10
 Put in the new control board, connect all electrical contacts and re-assemble
the unit in reverse order.
3.3.11 Checkup the imbalance sensor
Movement sensor:
• It is possible to adjust/correct the imbalance cut off value see chapter 2.2.2.
• Should appear any difficulties with the imbalance, please give us an exact description of it
as well as the serial number of the unit and the rotor type.
