4. Component replacement
Do not touch this area with grease.
Grease spreading method
Roller-Assy. -BIAS(FU)C
Cassette-Assy-PX741
Shaft-Liftup
Shaft-Liftup
Plate-Receive
Plate-Receive
EM-30L Class B
Apply a small amount of
MOLYKOTE(EM-30L) to sliding
portions of sheet metal and
shaft(the hatched area)
