Replacing Consumables7-6
7 Check that the toner cartridge to be replaced has been moved to the front.
" You can identify the toner cartridge by the color of the handle.
8 Pull down the handle on the
toner cartridge until the toner
cartridge is unlocked and moves
out slightly toward you.
Remove the toner cartridge.
" Do not manually rotate
the toner cartridge carou-
sel. In addition, do not
rotate the carousel with
force, otherwise it may be
damaged.
Note
Do not touch the contact
indicated in the illustration.
To Next Page
