Oki MC561 User Manual

44473001TH Rev.1
145 /
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
Item1 Item2 Item3 Item4 Item5 Value
Default
value
ODA
Default
value
OEL
Default
value
JP
Notes
Password ADF
(Back-side)
Mechanical
Test
FBS Test Speed Color 300x300dpi
Color 300x600dpi
Color 600x600dpi
Mono
Conduct mechanical testing (without reading an image).
A
DF : Test moving original document (stops when set document has been moved)
May choose from single- or double-sided feeding.
F
B
S : CIS moving test (stops after designated number of operations)
Use fastest read speed (40 cpm).
Display "Testing" during execution?
→
On the panel, indicate current number of executions using the message "Test no. xxx
underway."
TImes 0~65535
Execute --results--
Test no. xxx underway
Sensor
Test
Should input wording ① ~ ⑤ be
displayed in the right cell?
→
Display in the right cell the
wording in parentheses in ① ~ ⑤
and the state of each sensor (H/L).
Examples of this display are
shown below:
①
M
E
DIA H/L
②
S
C
AN H/L
③
RE
VERSE H/L
④
AD
F CVR H/L
⑤
FB H
/L
Display sensor status (H/L) in real time. Change the content of the display as needed
when the sensor status displayed changes.
①
Set-document detection sensor (MEDIA)
②
Scanning sensor (SCAN)
③
Reverse sensor (REVERSE)
④
ADF cover-open senor (ADF CVR)
⑤
FB home-position sensor (FB HP)
ADF Motor
Test
Forward
Forward Continuous
Reverse
Reverse Continuous
Test the ADF motor
①
After a short press of the button, rotate in the CW direction for 10 seconds and then stop.
②
Af
ter a long press of the button, rotate in the CW direction continuously. Stop when the
Stop button is pressed.
③
A
f
ter a short press of the button, rotate in the CCW direction for 10 seconds and then
stop.
④
A
f
ter a long press of the button, rotate in the CCW direction continuously. Stop when the
Stop button is pressed.
Deemed successful at all times. No need to display results.
Display "Testing" during execution?
→
Display a message on the panel showing that testing is underway.

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
