Oki MC561 User Manual

44473001TH Rev.1
171 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
No. Category
PJL
Status
Code
Error Warning Description
10 Normal 40967 1
2
3
4
5
Please check data.
Program Data Receive Error
<%DLCODE%>
An error has happened
while the printer is receive-
processing the NIC download
data.
%DLCODE%
1: File size error
2: Check-sum error
3: Invalid printer model number
4: Invalid module I/F version
5: Invalid FAT version
11 Normal 40967 1
2
3
4
5
Wait a moment.
Program Data writing ...
The printer is writing the NIC
download data.
12 Normal 40967 1
2
3
4
5
Power OFF/ON
Program Data written OK.
The printer finished writing
the NIC download data.
13 Normal 40967 1
2
3
4
5
Please check data.
Program Data Write Error
<%DLCODE%>
An error has happened while
the printer is writing the NIC
download data.
%DLCODE%
1: Memory allocation error
2: Download file error
3: Device allocation error
4: No device space
5: File writing failure
6: CU-F/W mismatch
14 Normal 10798 1
2
3
4
5
SIP update in progress. Indicates that downloading
the SIP firmware data.
No. Category
PJL
Status
Code
Error Warning Description
15 Normal - 1
2
3
4
5
Please check data.
Program Data Write Error
<%DLCODE%>
Indicates that an error has
happened while writing the
SIP download data.
%DLCODE%
1: Data transfer error
2: No device space
3: Check sum error
4: Chip detection error
5: Chip erace error
6: Chip writing error
7: Chip verify error
8:
Data error
(Product code is wrong e.t.c.)
9: Data size error
16 Normal 10795 1
2
3
4
5
%RDYMSG% Indicates that the unit date is
being updated by using PJL
command.
17 Normal 10796 1
2
3
4
5
%RDYMSG% Indicates that the requested
process is finished.
"Passed" is displayed, if
the process is completed
correctly.
"Failed" is displayed, if the
process is finished with an
error.
This indication disappear
automatically after it displayed
for three seconds.
18 Normal 10759 1
2
3
4
5
Wait a moment.
Executing maintenance.

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
