Oki MC561 User Manual

44473001TH Rev.1
170 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
Normal
No. Category
PJL
Status
Code
Error Warning Description
1 Normal 40988 1
2
3
4
5
PU downloading ... Downloading PU F/W (This is
not user-level error)
This function is secret to
users. Therefore, this status
does not occur in a user
environment.
2 Normal - 1
2
3
4
5
Updating ROM.
Please keep power ON.
Downloading scanner unit
(Scanner, Fax, Panel) FW.
3 Normal 40825 1
2
3
4
5
Wait a moment.
Message Data processing ...
Indicates that message
data to be updated is being
processed.
4 Normal 40826 1
2
3
4
5
Wait a moment.
Message Data writing ...
Indicates that message data
to be updated is being written.
5 Normal 40827 1
2
3
4
5
Power OFF/ON
Message Data written OK.
Indicates that message data
to be updated has been
written successfully.
No. Category
PJL
Status
Code
Error Warning Description
6 Normal 40828 1
2
3
4
5
Please check data.
Message Data Write Error
%CODE%
Indicates that writing of
message data to be uploaded
has been failed.
%CODE% is a decimal value
(one digit) and represents the
cause of failure in writing.
= 1 … FAIL: Other errors.
= 2 … DATA_ERROR: Hash
check error in data
reading/writing, or
abnormal FLASH
= 3 … OVERFLOW:
Downloading failure
due to FLASH memory
full at starting or during
writing in a language
file
= 4 … MEMORYFULL:
Memory reservation
failure
= 5 … UNSUPPORTED_DATA:
Downloading data
unsupported on the
MFP
7 Normal 30993 1
2
3
4
5
Wait a moment.
Network initializing ...
This appears when the NIC
initialization is occurred, as
the setting was changed.
8 Normal 40967 1
2
3
4
5
Wait a moment.
Program Data receiving ...
Indicates that receiving the
NIC download data.
9 Normal 40967 1
2
3
4
5
Wait a moment.
Program Data received OK.
Indicates that finished
receiving the NIC download
data.

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
