7. TROUBLESHOOTING PROCEDURES
No. Category
PJL
Status
Code
Error Warning Description
70 Normal 10863 1
2
3
4
5
<Scan To Mail/ Network PC
Screen>
<ScanToUSBMemory>
<PCScan/PushScan>
Refer to T14_Massage during
execution
：
FX750 Massage during
execution
_verxx.xx.doc
(xx.xx is version)
<StatusAP>
Scanning ...
<Fax Sending Screen>
Scanning ...
%TXPAGE% Page(s)
%DOC_SIZE%
<Fax Manual Sending Screen>
Manual Fax sending: Sending ...
%TXPAGE% Page(s)
%DOC_SIZE%
Indicates that it is scanning of
documents.
The screen image in ScanTo:
"Sample Screen" sheet -
no.17
The screen image in Fax
Sending: "Sample Screen"
sheet - no.16
The unit of "Page" is
"Impression".
In duplex scanning, "Page"
counter is increased by 1
when the front side of sheet
scanning started, and the
counter is increased by 1
when the back side scanning
started.
%LOCATION_INFO%:
Location Information (
（
Scan
To Mail, Scan To Network PC
only)
%SCAN_PAGE%: the number
of current scanning page.
%DOC_SIZE%: Document
size
Scan Size setting is "Auto":
the detected document size.
Scan Size setting isn't "Auto":
the selected scan size.
No. Category
PJL
Status
Code
Error Warning Description
63 Normal 10994
10988
1
2
3
4
5
Preparing ... Executing Auto Density
Adjustment.
Status code 10988
corresponds to density
reading , thereto 10994
corresponds to density
adjusting.
64 Normal 32002 1
2
3
4
5
File System is full.
Please see Help for details.
Disk-full is occurring. Because
this is a temporary warning,
it remains until the end of the
job and disappears.
65 Normal 32026 1
2
3
4
5
File System is write protected.
Please see Help for details.
An attempt to write in a read-
only file was done. Because
this is a temporary warning,
it remains until the end of the
job and disappears.
66 Normal 10898 1
2
3
4
5
File erasing ... Indicates that a secret file is
being erased.
67 Normal 30961 1
2
3
4
5
Deleting encrypted job. It indicates the deletion of
encrypted authentication print
job and saving of deletion
request of file.
68 Normal 30956 1
2
3
4
5
Wait a moment.
Network Configuration writing ...
This appears during the NIC
configuration data is storing
into the flash memory, as the
setting was changed.
69 Normal - 1
2
3
4
5
Cancelling ... Indicates that copy job is
cancelling.
