7. TROUBLESHOOTING PROCEDURES
No. Category
PJL
Status
Code
Error Warning Description
71 Normal - 1
2
3
4
5
Scan Pages sss
Print Pages ppp
Copy aa/bb
-------------------------------------------
----
<Message during StatusAP>
-
Indicates that it is copying.
sss: the number of current
scanning page.
ppp: the number of current
printing page.
aa: the number of current
printing.
bb: the total number of
printing.
The unit of "Scanned pages"
is "Impression".
For example, in duplex
scanning, "Scanned pages"
counter is increased +1 at the
front side of sheet scanning
started, and the counter is
increased +1 at the back side
scanning started.
The unit of "Print pages" is
"Impression".
In simplex printing, "Print
page" counter is increased by
1 when the paper exited from
fuser.
In duplex printing, "Print
page" counter is increased
by 2 when the paper exited
from fuser (after the back side
printed out).
No. Category
PJL
Status
Code
Error Warning Description
72 Normal - 1
2
3
4
5
<Copy Screen>
Please set next document.
------------------------------
<Scan To, Fax Sending Screen>
Please set next document.
This screen is displayed
at the time of the scanning
completed in Job Build = ON.
Copy: "Sample Screen" sheet
- no.28
ScanTo: "Sample Screen"
sheet - no.29
Fax Sending: "Sample
Screen" sheet - no.30
73 Normal 10861 1
2
3
4
5
Cancelling ... Indicates that the scanning
for Scan To USB memory is
cancelling by the pressing
Stop key.
74 Normal 10859 1
2
3
4
5
Data writing to USB Memory. Indicates that it is wrighting
the image file to USB memory
after the scanning completed.
The cancel operation by
STOP key pressing is
unsupported during the
writing to USB memory.
75 Normal 10797 1
2
3
4
5
Connecting to PC ... Indicates that it is connecting
to PC.
This message will be
displayed at Start key pressed
after the orignal document
set.
76 Normal - 1
2
3
4
5
Telephone
Please see Help for details.
The screen that specified
talking by telephone is
displayed, when [OffFook]
button pressed or the handset
hooked up.
77 Normal - 1
2
3
4
5
Telephone Indicates that tha fax
receiving started.

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
