7. TROUBLESHOOTING PROCEDURES
No. Category
PJL
Status
Code
Error Warning Description
78 Normal - 1
2
3
4
5
Fax receiving ...
Page: %RXPAGE%
========
[F-code PollingRX]
Fax receiving ...
Page: %RXPAGE%
%RXFAXNUMBER%
Indicates that it is receiving
fax data.
%RXPAGE% : number of the
current receiving page
%RXFAXNUMBER% :
sender Fax no.
（※Ｆ
-code
PollingRX only
）
In the case that the F-code
PollingRX is done by using
speed dial, display field is the
following...
A dial number is displayed
during dialing
An entry name is displayed
in fax no. field during fax
receiving.
79 Normal - 1
2
3
4
5
Fax receiving ...
Page: %RXPAGE%
========
[F-code PollingRX]
Fax receiving ...
Page: %RXPAGE%
%RXFAXNUMBER%
Indicates that it is receiving
fax data.
%RXPAGE% : number of the
current receiving page
%RXFAXNUMBER% :
sender Fax no.
（※Ｆ
-code
PollingRX only
）
In the case that the F-code
PollingRX is done by using
speed dial, display field is the
following...
A dial number is displayed
during dialing
An entry name is displayed
in fax no. field during fax
receiving.
No. Category
PJL
Status
Code
Error Warning Description
80 Normal - 1
2
3
4
5
Fax calling ...
%TXFAXNUMBER%
Indicates that it is calling.
%TXFAXNUMBER%
：
fax
number of the calling.
81 Normal - 1
2
3
4
5
Fax calling ...
%TXFAXNUMBER%
Indicates that it is negotiating.
%TXFAXNUMBER%
：
fax
number of the calling.
82 Normal - 1
2
3
4
5
Fax sending ...
Page: %TXPAGE%
%TXFAXNUMBER%
========
[F-code PollingTX]
Fax sending ...
Page: %TXPAGE%
Indicates that it is sending fax
data.
%TXPAGE% : number of the
current receiving page
%TXFAXNUMBER% :
recipient Fax no.(Not display
on F-code PollingTX)
In the case of manual fax
sending, "Manual Fax
sending: Sending ..." is
displayed on LCD. Scan page
count and document size are
displayed in the left bottom.
Page number, Fax no. are not
displayed.
In the case that the fax
sending is done by using
speed dial, fax no. is
displayed during both dialing
and sending.

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
