Oki MC561 User Manual

44473001TH Rev.1
182 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
No. Category
PJL
Status
Code
Error Warning Description
98 Normal 10807 1
2
3
4
5
Check Message printing ... Indicates that printing of fax
communication error report.
99 Normal 10808 1
2
3
4
5
Fcode Box Journal printing ... Indicates that printing of
the message report that fax
receiving data is sroted in F
code box by F code receiving.
100 Normal 10809 1
2
3
4
5
Erased Report printing ... Indicates that printing of
the message report that the
stored fax data in memory
was eraced.
101 Normal 10810 1
2
3
4
5
Fcode Box List printing ... Indicates that printing of the
enabled F code box list.
102 Normal 10811 1
2
3
4
5
Block Junk Fax List printing ... Indicates that printing of
the location list that is not
permission to receive fax.
103 Normal 10812 1
2
3
4
5
Stored Doc. List printing ... Indicates that printing of the
stored fax image data list.
104 Normal 10793 1
2
3
4
5
Data transmission in progress. Indicates that scanned image
data sending to PC.
No. Category
PJL
Status
Code
Error Warning Description
105 Normal - 1
2
3
4
5
- This status is for confirming
the number of copy job.
It is controlling status and
used for judging if copy job
can be started. It does not
have relation with a change of
indication.
106 Normal - 1
2
3
4
5
- This status is for confirming
the number of print job.
It is controlling status and
used for judging if copy job
can be started. It does not
have relation with a change of
indication.
107 Normal 10839 1
2
3
4
5
Preparing ... Indicate that the unit is
preparing to be able to use
the replaced expendable
supplies.
This message is displayed
at the time of toner cartriges
replaced.
108 Normal 10838 1
2
3
4
5
Cancelling ... Indicates that the image data
writing to USB memory is
cancelling.
This massage is displayed
when an error is occurred
during the data writing to USB
memory.
The key operation is
disableed during this
message displayed.
109 Normal - 1
2
3
4
5
Fax Rx Doc. printing ... Printing fax Received Data.

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
