Oki MC561 User Manual

44473001TH Rev.1
187 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
No. Category
PJL Status
Code
Error Warning Description
20 Warning 10882 1
2
3
4
5
Density Black Sensor Error Density Adjustment Black
Sensor Error.Error that
does not occur at user
level.Displayed only in
FactoryMode.
PU firmware does not
notify this warning to
CU firmware at the
time of Shipping Mode.
Therefore, this status
does not occur in a user
environment.
21 Warning 10976 1
2
3
4
5
%COLOR% Image Drum Smear
Error
Density Adjustment ID
ERROR 2; smear due to
ID failure.
PU firmware does not
notify this warning to
CU firmware at the
time of Shipping Mode.
Therefore, this status
does not occur in a user
environment.
%COLOR%
Y
M
C
K
No. Category
PJL Status
Code
Error Warning Description
22 Warning 10975 1
2
3
4
5
%COLOR% Low Density Error Density Adjustment ID
ERROR; LED out of focus
is assumed.
PU firmware does not
notify this warning to
CU firmware at the
time of Shipping Mode.
Therefore, this status
does not occur in a user
environment.
%COLOR%
Y
M
C
K
23 Warning 10054 1
2
3
4
5
Sensor Calibration Error When output of color
registration sensor is
below reference value.
PU firmware does not
notify this warning to
CU firmware at the
time of Shipping Mode.
Therefore, this status
does not occur in a user
environment.
24 Warning 10051 1
2
3
4
5
Registration Error <%CODE%> When a color registration
error is detected with
coarse adjustment, or
with the main-scan line
adjustment.
PU firmware does not
notify this warning to
CU firmware at the
time of Shipping Mode.
Therefore, this status
does not occur in a user
environment.
%CODE%
2 = Yellow
3 = Magenta
4 = Cyan
5 =

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
