44473001TH Rev.1
188 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
No. Category
PJL Status
Code
Error Warning Description
25 Warning 10052 1
2
3
4
5
Registration Sensor Error
<%CODE%>
When a color registration
error is detected with the
fine control of registration
adjustment, or with the
sub-scan line adjustment.
PU firmware does not
notify this warning to
CU firmware at the
time of Shipping Mode.
Therefore, this status
does not occur in a user
environment.
%CODE%
2 = Yellow
3 = Magenta
4 = Cyan
5 =
26 Warning 10945 (Y)
10946 (M)
10947 (C)
10944 (K)
1
2
3
4
5
%COLOR% Head Data Error The LED head calibration
data is missing or invalid.
Printing can be proceeded
without calibrating light
radiation.
PU firmware does not
notify this warning to
CU firmware at the
time of Shipping Mode.
Therefore, this status
does not occur in a user
environment.
%COLOR%
Y
M
C
K
27 Warning 1601x
x: Tray #
1
2
3
4
5
%TRAY% Empty
Please see Help for details.
%TRAY%: The tray
is empty. Treated as
Warning until printing
to the empty tray is
designated.
%TRAY%
Tray1
Tray2
No. Category
PJL Status
Code
Error Warning Description
28 Warning 1090x 1
2
3
4
5
%TRAY% missing.
Please see Help for details.
Indicates that paper trays
are not installed.
%TRAY%
Tray1
29 Warning 10814 1
2
3
4
5
Accounting Log Buffer is near full.
Please see Help for details.
It indicates the Job
Accounting log buffer is
near full.
30 Warning 10787 1
2
3
4
5
Accounting Log Buffer Full (Delete
old logs)
The function isn't
accepted because log
buffer is full. (Related to
JobAccount).
This message is
displayed, if the log buffer
is full and "Operation
at Log Full" in Job
Accounting Server
Software is set to "Delete
old logs".
The new jobs will be
able to execute after the
following operations.
1. The log in the unit must
be got by Job Accounting
Server Software.
2. The setting of
"Operation at Log Full"
must be changed to
"Does not acquire logs".
31 Warning 10072(Y)
10073(M)
10074(C)
10071(K)
1
2
3
4
5
Please check %COLOR% Toner
Cartridge.
Please see Help for details.
Something is wrong with
the toner sensor during
printing.
%COLOR%
Y
M
C
K
