Troubleshooting > 154
3. Press the cover release (a) and open the MFP’s top cover (b) fully.
4. If the paper is advanced far enough, grip it and pull it gently out. If necessary, rotate
roller (1) to advance the paper and aid removal.
5. Note the positions of the four cartridges. It is essential that they go back in the same
order.
WARNING!
If the MFP has been powered on, the fuser may be hot. This area is
clearly labelled. Do not touch.
NOTE
If no paper is visible follow the next steps to remove it from the MFP.
1. Cyan cartridge 3. Yellow cartridge
2. Magenta cartridge 4. Black cartridge
b
a
1
2
