ML1120/ML1190 eco User’s Guide – Troubleshooting > 92
Improper continuous forms feed.
No line feed, and no
paper feed.
Paper is off the Pin
Tractors.
Reload paper correctly.
The adjust lever
position does not match
the paper type.
Set the adjust lever to
the correct position.
Paper distortion or jam. Forms are loaded with
their left holes out of
line with the right ones.
Load forms with their
left holes in line with
the right ones.
Inadequate distance
between the left and
right Pin Tractors,
making for loose paper.
Relocate the Pin
Tractors to tighten the
paper.
Paper movement is
blocked.
Remove the blockage.
Paper source is too far
from the printer.
Move the paper source
nearer to the printer.
Paper not specified for
the printer.
Use paper types
specified for this printer.
Several blank lines
appear in the printout.
Skip over perforation
spacing is selected.
Cancel the skip over
perforation spacing.
The selected skip over
perforation spacing
does not match the
physical tear-off
perforation positions.
The paper length
selected in the
application does not
match the physical
paper length.
Match the paper length
selected in the
application with the
physical paper length in
use.
Select the paper length
in number of lines in the
application.
Abnormal switchover between cut sheet and continuous forms modes.
No cut sheet feed. The printer is in
continuous forms mode.
Set the Paper Type lever
to cut sheet mode.
No continuous forms
feed.
The printer is in cut
sheet mode.
Set the Paper Type lever
to continuous forms
mode.
Paper feed operations
for both cut sheets and
continuous forms are
actuated.
The cut sheet is not
ejected.
Eject the cut sheet.
PROBLEM CAUSE ACTION

Oki ML1120 Specifications

General

Noise level	49.7 dB
Maximum duty cycle	18000 pages per month
Maximum number of copies	9 copies
Power requirements	120 - 220V
Dimensions (WxDxH)	889 x 587 x 379 mm

Weight and Dimensions

Dimensions (W x D x H) (imperial)	35 x 23.1 x 14.9 \
