21.3 T1-MODULE
Technical Data
Sensor
K-type Thermocouple. PFA-insulated: Length 2m; OD:
0.13mm
Range
0-60°C
Accuracy (from 20 to 50°C)
± 0.1°C
Figure 119. T1-MODULE-Technical drawing
21.4 T2-MODULE
Technical Data
Sensor
PT1000 RTD Class A. Probe Length: 150mm; OD: 2.0mm;
Cable Length: 1m
Range
0-60°C
Accuracy (from 20 to 50°C)
± 0.1°C
Figure 120. T2-MODULE-Technical drawing
