Installation
|
Installing Optional Devices
16
VFD
Installing the VFD
To install the VFD, follow these steps:
1.
Remove the I/O port cover by following the instructions in “Removing the I/O port cover“ on
page 10.
2.
Detach the plate on the I/O port cover to make space for installing the VFD.
NOTE:
⦁
Completely remove the plate, ensuring that no sharp parts remain. There is the risk of injuring yourself if the
sharp edges are not completely removed.
3.
Place the VFD and tighten it with two thumbscrews.
To Next Page
