OKPOS Optimus - Components Replacement; Replacing the M.2 SSD

System Disassembly
|
Components Replacement 30
Components Replacement
Replacing the M.2 SSD
To replace the M.2 SSD, follow these steps:
1.
Turn o the system and peripheral devices.
2.
Remove the I/O port cover by following the instructions in “Removing the I/O port cover“ on
page 10.
3.
Remove the stand’s rear cover by following the instructions in “Removing the stand’s rear cover“
on page 11.
4.
Remove the power cord and all cables from the system.
5.
Place the touch LCD panel side down on a soft, at surface. (Be careful not to damage the touch
LCD panel.)
6.
Remove the card reader or dummy cover by following the instructions in “➊ Removing the
cover“ on page 22.
7.
Remove the screw and the M.2 SSD card from the slot.
