System Boards
|
Main Board 60
1
System fan header
2
Realtek RTL 8111F LAN controller
3
ITE IT8766E-I super I/O controller
4
CMOS battery
5
COM and SATA connector
6
Clear CMOS jumper
7
Buzzer
8
USB 8 pins FPC connector for touch
9
Speaker header
10
CPU
11
LVDS header
12
Front panel header
13
USB ports
14
M.2 SATA2 2260/2280 SSD socket
15
Power button
16
Memory socket
17
Realtek Codec ALC662 audio controller
18
I/O ports
