Hardware Overview iTrans Fixed Point Single/Dual Gas Monitor
2-2 iTrans User Manual (P/N: 77023554-1)
2.2. Sensor
Table 2-3. Sensor Specifications
Item
Descriptions
Catalytic and Toxics
Infrared (BBIR)
Sensor
Housing
Material
Aluminum, Anodized
Explosion-proof: Class I, Divisions 1
and 2, Groups B, C, D and Ex d IIB
+H2 T5 (ATEX and IECEx), Ex d
IICT6 Gb (China)
Stainless Steel
Explosion-proof: Class I,
Divisions 1 and 2 Groups B,
C, D, and Ex d IIB +H2 T4
(Europe), Ex d IIC T4 or IIC
T6 (China)
Aluminum, Anodized w/Gore-Tex
Membrane: Class I, Division 2, Groups
A, B, C, D and Ex nA IIC T5 (IECEx)
and Ex nA II T5 (ATEX).
Dimensions
3.0  3.0 inches (76  76 mm)
3.5  3.0 inches (89  76 mm)
Accuracy
<  3% Toxic and Oxygen
<  5% Combustibles
Protection
Class
IP 66 or NEMA4X
